Dual Purpose magnetic and penetrant set

A set of 10 small, lightweight, and convenient to handle weld specimens, each containing either 1 or 2 commonly occurring surface-breaking flaws, with a minimum of 18 flaws per set.

Designed for practical training, each set contains 2 tee and 8 plate specimens and is presented in a durable polypropylene carry case with high-density foam inserts to ensure total protection of the specimens.

Recommended for:

  • Introduction to basic flaw detection, sizing and interpretation
  • Understanding simple weld geometries

Each set contains:

  • 10 small, flawed specimens
  • An average of 18 real flaws
  • Flaw location details
  • Testing and acceptance criteria
  • Certificate of conformance
  • Drawing / NDE Report(s) showing overall size, flaw type/size/location
FS-07

$2,285.00

Dual Purpose magnetic and penetrant set

$2,285.00

Specification

Product dimension

2 tee - 4” x 8” x 0.25” WT SV

8 plate - 4” x 8” x 0.25” WT SV

Weight

14 kg / 31 lbs

Material

Carbon steel

Method

Magnetic particle testing & Liquid penetrant testing

Custom specimen designs, material types and flaw locations are available, please contact us for more details.
